8 & 10 bar OPC 90-132 / 8 bar & 10 bar
15 to 23 m³/min FAD
Caracteristics
-
Nominal capacity
from 15 to 23 m³/min
-
FAD
530 to 812 CFM
-
Motor power
from 90 to 132 kW
-
MSF
Motor Service Factor 1.0
-
Capacities ISO 1217
| Model | Capacity m3/min | Capacity m3/h FAD | Capacity CFM | Installed power kW |
|---|---|---|---|---|
| OPC 90 - 8 | 16,5 | 990 | 583 | 90 |
| OPC 110 - 8 | 20,0 | 1200 | 706 | 110 |
| OPC 132 - 8 | 23,0 | 1380 | 812 | 132 |
| OPC 90 - 10 | 15,0 | 900 | 530 | 90 |
| OPC 110 - 10 | 18,0 | 1080 | 636 | 110 |
| OPC 132 - 10 | 21,5 | 1290 | 759 | 132 |
Options
Design
Recovery
Control and Monitoring
Regulation
40 bar Certifications & Equipment Options
Electrical options
Protection for hot and cold environments
Separate cooling systems
Optimal operating in hot and tropical areas
Electrical motor / Service factor 1.0
